Item specifics
  • Brand Name: blueskysea
  • Product Type: Portable Scanner
  • Interface Type: USB
  • Type: Barcode Scanner
  • Model Number: H220B
  • Novelty: New
  • Scan Breadth: bar code
Product Description





Free Shipping!CCD Image Bluetooth 1D Barcode Reader for Android IOS Iphone Support Mobile Payment Computer Screen Barcode Scanner


Note pls!It can only scan one-dimensional barcode.



Note pls!It can only scan one-dimensional barcode.



H220B is handheld scanner can handle all of photosensitive one-dimensional barcodes, ideal for small retailers to use.

H220B uses Linear Imaging sensitive technology: quick scan bar codes, even in poor print quality or corrupted scanning barcodes, but also has good decoding performance.

High sensitivity CCD linear image sensor scanning module/scan module, barcode scanning rate of up to 200 times / sec is the best choice CCD type barcode scanning module to fit applications requiring high performance, compact and reliable operation.



Specification

Wireless module

Bluetooth communication

Scan mode

Manual

Indicator

LED blue,LED red

Buzzer

a buzzer

Power supply

built-in rechargeable lithium battery

Setting mode

default or manually (one scan barcodes)

Communication distance

10 meters

Optical System

2500 pixels CCD sensor

Light source

LED (wavelength 660nm ± 10nm)

Scan speed

200 times / sec

Scan angle

30 angle from 37 elevation

Maximum scanning distance

(60% contrast)

(15mil) 32cm, (10mil) 22cm, (5mil) 11cm, (4mil) 7cm,(3mil)3cm

Low Contrast

30%

Resolution

>3mil

Scanning width

< 110mm

Read symbologies

Code 39, Full ASCII Code 39, Code 32, Code 128, Code 93, Code 11, Codabar / NW7, All UPC / EAN /

JAN code (EAN-13, EAN-8, UPC-A, UPC- E, EAN-128), Interleave 2 of 5, STD 2of 5, Industrial 2 of 5,

matrix 2 of 5, Chinese Postage Code, IATA, MSI / PLESSY, Italian Pharmacy Code, Industrial 2 of 5, BC-412

Memory capacity

512KB,can store up to 10K barcodes

Input voltage

DC 5V ± 5%

Quiescent Current

35mA

Working Current

100mA

Dimensions

180mm(L)x 65mm(W)x105mm(H)

Weight

189 g (without cable)

Cable Standard

straight, 2 m

Interface Type

USB interface (computer terminal)

Shell Material

ABS

Color

Black

Temperature

0C to 45C (work); - 20C to 45C (storage)

Humidity

5-95% (non-condensing)

ESD protection

± 15kVDC air discharge, ± 8kVDC direct / indirect discharge

The light intensity

Daylight 7.000luX max



Note please!Its USB cable can only recharge for scanner.It can not be used as wired scanner.



What has included in the package?

(Note pls!package doesn\'t offer USB bluetooth adapter.If your device can not support bluetooth function,it can not support my scanner H220B.)

H220B scanner*1 pcs

USB cable *1 pcs

Manual*1 pcs

Packaging Details
  • Unit Type: piece
  • Package Weight: 0.4kg (0.88lb.)
  • Package Size: 15cm x 12cm x 7cm (5.91in x 4.72in x 2.76in)
